Product Dimensions
-4 9/16” (W) x 5 1/16” (H) x 1 3/4” (D) Lamp
Product Installation
-Multi-Position Mounting Bracket
-Includes 3/8" Stainless Bolt/Nut
Product Construction
-Acrylic Lens
-Die Cast Aluminum Housing
-Black High UV Resistant Powder Coat
-IP67 Waterproof
Product Wiring
-Two-wire Power/Ground Pigtail
-Reverse Voltage Protection
Product Light Output
-Flood Beam Pattern
-10 x 1 Watt LED (30,000 Hour Rated)
-900 Lumen Output
-Beam Penetration Up To 200 Feet
Product Operation
-9-36 VDC Operating Voltage
-1.3 Amp Draw At 12 Volts
Product Compliance
-RFI/EMC
-RoHs Compliant
-ASTM B117 Corrosion Protection Compliant
